Two sets of chargers with two sets of batteries and two sections of busbars increase the reliability of the entire system's power supply

The power supply between busbars can be switched and connected to each other

Ø Adopting a large touch screen, fully localized real-time display and operation, user-friendly human-machine interface

Wide voltage input range and strong adaptability to the power grid

Ø Adopting high-frequency switching power supply technology, modular design, N+1 hot backup

Ø The charging module can be plugged in and out with power, making maintenance convenient and fast

Ø Adopting autonomous current sharing technology, the imbalance of current sharing is ≤± 3%

The charging module adopts frequency conversion natural resonance soft switching technology, with an efficiency of ≥ 96%

The monitoring system adopts a modular structure, and all communication between monitoring units is electrically isolated, which improves the reliability of the monitoring system

Intelligent battery management with automatic battery management and automatic temperature compensation functions

Equipped with RS232/RS485 communication interface and multiple built-in communication protocols, it is more convenient to communicate with remote monitoring systems to achieve the "four remote" function and achieve unmanned operation

Communication input:

Rated input voltage: AC380V

Frequency variation range: 50HZ ± 10%

DC output

Output voltage: 110V, 220V

System composition:

Charging screen:

AC power distribution: Two AC 380V power inputs, capable of automatic switching and mutual backup

Lightning protection unit: lightning protection and overvoltage protection

Charging module: intelligent self cooling 110/220V, 10A, 20A, and 40A modules

Monitoring module: the core management component of the system, which automatically completes the charging and discharging functions of the battery. It is fully localized, with a large screen LCD display, and can achieve "remote control, telemetry, remote signaling, and remote adjustment" functions

Size: 2260mm (height) * 800mm (width) * 600mm (depth) (customizable according to user requirements)

Feeding screen: (The number of screens is selected according to the specific plan)

Feedback circuit: configurable with 6 channels, 16-300A molded case circuit breakers; Configure 30 circuits, 10-50A molded case circuit breakers, and choose the capacity, quantity, and brand of circuit breakers according to user requirements

Feed out circuit detection module: detects the trip signal of each feed out circuit, with a maximum of 32 circuits detected per module. The system can be configured with multiple detection modules
