Power supply: 80VDC~300VDC

◆ Function:

① Detect 4-channel single-phase/three-phase AC voltage;

② Detect 15 switch inputs and control 15 dry contact outputs;

③ Cooperate with the dip switch to achieve parallel connection of two machines;

④ Provide two communication interfaces: RS485 and CAN.

Detection range and error:

Three phase AC voltage: 0-480V, with an error of 2V;

◆ Communication: Isolated RS485 communication and isolated CAN communication

◆ Dimensions: 224.3mm × 110.3mm × 35.6mm (length × width × height)

Hole size: 213.5mm × 82mm
